TFT Specifications

TFT Modules

ASI-T-500MA4F6/B is a 5.0 inch TFT with 24-bit RGB Interface, wide operating temperature, all-view and a capacitive touch panel.

PRODUCTS SPECS
PDF

Interface RGB
Size 5
Touch Panel Capacitive Touch Panel
Brightness/Nits Range 400-699
Resolution

800 x 480

Module Size

120.7 x 75.80 x 4.67

Active Area

108.00 x 64.80

Polarizer Transmissive
Brightness/Nits 480
Viewing Direction IPS/All-view

ASI-T-500MA6F5/D is a 5 inch high brightness TFT with a resolution of 800 x 480, RGB interface and with a brightness of 690 Nits; viewable in direct sunlight with Capacitive Touch Panel

PRODUCTS SPECS
PDF
Interface RGB
Size 5
Touch Panel Capacitive Touch Panel
Brightness/Nits Range 400-699
Resolution 800 x 480
Module Size 121.1 x 76.2 x 5.0
Active Area 108.0 x 64.8
Polarizer Transmissive
Brightness/Nits 690
Viewing Direction 12:00

ASI-T-500MA8AN/D is a 5 inch high brightness TFT with a resolution of 800 x 480, RGB interface and with a brightness of 800 Nits; viewable in direct sunlight.

PRODUCTS SPECS
PDF
Interface RGB
Size 5
Touch Panel None
Brightness/Nits Range 700-999
Resolution 800 x 480
Module Size 120.7 x 75.8 x 3.1
Active Area 108.0 x 64.080
Polarizer Transmissive
Brightness/Nits 800
Viewing Direction 12:00

ASI-T-500MB2FT/D is a 5 inch TFT with a resolution of 800 x 480, RGB 24 Bits interface, a brightness of 240 Nits with a Resistive Touch Panel.

PRODUCTS SPECS
PDF

Interface RGB
Size 5
Touch Panel Resistive Touch Panel
Brightness/Nits Range 100-399
Resolution 800 x 480
Module Size 120.70 x 75.80 x 4.3
Active Area 108.00 x 64.80
Polarizer Transmissive
Brightness/Nits 240
Viewing Direction 12:00

ASI-T-500MB3FN/D is a 5.0 inch TFT with a resolution of 800 x 480, RGB interface and with a brightness of 300 Nits

PRODUCTS SPECS
PDF
Interface RGB
Size 5
Touch Panel None
Brightness/Nits Range 100-399
Resolution 800 x 480
Module Size 120.7 x 75.8 x 2.85
Active Area 108.0 x 64.80
Polarizer Transmissive
Brightness/Nits 300
Viewing Direction 12:00

ASI-T-560GA3RN/D is a 5.6 inch TFT with a resolution of 640 x 480, RGB interface and with a brightness of 350 Nits

PRODUCTS SPECS
PDF
Interface RGB
Size 5.62
Touch Panel None
Brightness/Nits Range 100-399
Resolution 640 x 480
Module Size 126.50 x 100.00 x 5.7
Active Area 112.89 x 84.67
Polarizer Transmissive
Brightness/Nits 350
Viewing Direction 12:00
ASI-T-560GA8AN/D is a 5.6 inch high brightness TFT with a resolution of 640 x 480, RGB interface and with a brightness of 800 Nits; viewable in direct sunlight.
PRODUCTS SPECS
PDF

Interface RGB
Size 5.6
Touch Panel None
Brightness/Nits Range 700-999
Resolution 640 x 480
Module Size 126.50 x 100.00 x 5.7
Active Area 112.89 x 84.67
Polarizer Transmissive
Brightness/Nits 800
Viewing Direction 12:00

ASI-T-570EA14QN/D is a 5.7 inch high brightness TFT with a resolution of 320 x 240, 8-bit parallel / serial interface and with a brightness of 1400 Nits; viewable in direct sunlight.

PRODUCTS SPECS
PDF
Interface Other
Size 5.7
Touch Panel None
Brightness/Nits Range 1000 & up
Resolution 320 x 240
Module Size 159.5 x 108.4 x 6.35
Active Area 115.2 x 86.4
Polarizer Transmissive
Brightness/Nits 1400
Viewing Direction 6:00

ASI-T-570EA4AN/D is a 5.7 inch TFT with a resolution of 320 x 240, RGB interface and with a brightness of 400 Nits

PRODUCTS SPECS
PDF

Interface RGB
Size 5.7
Touch Panel None
Brightness/Nits Range 400-699
Resolution 320 x 240
Module Size 144 x 104 x 13.0
Active Area 115.2 x 86.4
Polarizer Transmissive
Brightness/Nits 400
Viewing Direction 6:00

ASI-T-570EA6TT/D is a 5.7 inch high brightness TFT with a resolution of 320 x 240, TTL interface and with a brightness of 650 Nits; viewable in direct sunlight with Resistive Touch Panel

PRODUCTS SPECS
PDF
Interface Other
Size 5.7
Touch Panel Resistive Touch Panel
Brightness/Nits Range 400-699
Resolution 320 x 240
Module Size 127.0 x 98.43 x 10.5
Active Area 115.2 x 86.4
Polarizer Transmissive
Brightness/Nits 650
Viewing Direction

ASI-T-570EA8TN/D is a 5.7 inch high brightness TFT with a resolution of 320 x 240, TTL interface and with a brightness of 800 Nits; viewable in direct sunlight.

PRODUCTS SPECS
PDF
Interface Other
Size 5.7
Touch Panel None
Brightness/Nits Range 700-999
Resolution 320 x 240
Module Size 127 x 98.43 x 9.2
Active Area 115.2 x 86.4
Polarizer Transmissive
Brightness/Nits 800
Viewing Direction

ASI-T-570EB4AN/D is a 5.7 inch TFT with a resolution of 320 x 240, RGB interface and with a brightness of 400 Nits

PRODUCTS SPECS
PDF

Interface RGB
Size 5.7
Touch Panel None
Brightness/Nits Range 400-699
Resolution 320 x 240
Module Size 144.00 x 104.60 x 13.0
Active Area 115.20 x 86.40
Polarizer Transmissive
Brightness/Nits 400
Viewing Direction IPS/All-view
ASI-T-570GA3T2/D is a 5.7 inch TFT with a wide operating temperature, resolution of 640 X 480, RGB interface, a brightness of 360 Nits with a Capacitive Touch Panel.
PRODUCTS SPECS
PDF
Interface RGB
Size 5.7
Touch Panel Capacitive Touch Panel
Brightness/Nits Range 100-399
Resolution 640 X 480
Module Size 144.0 X 104.6 X 12.3
Active Area 115.2 X 86.4
Polarizer Transmissive
Brightness/Nits 360
Viewing Direction

ASI-T-570GA4A2/D is a 5.7 inch TFT with a resolution of 640 x 480, RGB interface, a brightness of 450 Nits with a Capacitive Touch Panel.

PRODUCTS SPECS
PDF
Interface RGB
Size 5.7
Touch Panel Capacitive Touch Panel
Brightness/Nits Range 400-699
Resolution 640 x 480
Module Size 127.0 x 98.43 x 8.75
Active Area 115.2 x 86.4
Polarizer Transmissive
Brightness/Nits 450
Viewing Direction 12:00

ASI-T-570GA4AN/D is a 5.7 inch TFT with a resolution of 640 x 480, RGB interface and with a brightness of 400 Nits

PRODUCTS SPECS
PDF
Interface RGB
Size 5.7
Touch Panel None
Brightness/Nits Range 400-699
Resolution 640 x 480
Module Size 127 x 98.43 x 7.0
Active Area 115.2 x 86.4
Polarizer Transmissive
Brightness/Nits 400
Viewing Direction 12:00

ASI-T-570GA4NT/D is a 5.7 inch TFT with a resolution of 640 x 480, TTL interface, a brightness of 400 Nits with a Resistive Touch Panel.

PRODUCTS SPECS
PDF
Interface TTL
Size 5.7
Touch Panel Resistive Touch Panel
Brightness/Nits Range 400-699
Resolution 640 x 480
Module Size 127.0 x 98.43 x 9.6
Active Area 115.2 x 86.4
Polarizer Transmissive
Brightness/Nits 400
Viewing Direction 12:00
ASI-T-570GA4TN/D is a 5.7 inch wide TFT, with a wide operating temperature and a resolution of 640 x 480, RGB interface and a brightness of 400 Nits.
PRODUCTS SPECS
PDF
Interface RGB
Size 5.7
Touch Panel None
Brightness/Nits Range 400-699
Resolution 640 x 480
Module Size 144.00 x 104.60 x 12.30
Active Area 115.20 x 86.40
Polarizer Transmissive
Brightness/Nits 400
Viewing Direction 6:00

ASI-T-570GA8A2/D is a 5.7 inch high brightness TFT with a resolution of 640 x 480, RGB interface and with a brightness of 810 Nits; viewable in direct sunlight with Capacative Touch Panel

PRODUCTS SPECS
PDF
Interface RGB
Size 5.7
Touch Panel Capacitive Touch Panel
Brightness/Nits Range 700-999
Resolution 640 x 480
Module Size 127.0 x 100 x 8.56
Active Area 115.2 x 86.4
Polarizer Transmissive
Brightness/Nits 810
Viewing Direction 12:00

ASI-T-570GA8AN/D is a 5.7 inch high brightness TFT with a resolution of 640 X 480, RGB interface and with a brightness of 900 Nits; viewable in direct sunlight.

PRODUCTS SPECS
PDF
Interface RGB
Size 5.7
Touch Panel None
Brightness/Nits Range 700-999
Resolution 640 X 480
Module Size 127.0 x 98.43 x 7.0
Active Area 115.2 X 86.4
Polarizer Transmissive
Brightness/Nits 900
Viewing Direction 12:00
ASI-T-650GA8LN/D is a 6.5 inch high brightness TFT with a resolution of 640 X 480, LVDS interface and with a brightness of 800 Nits; viewable in direct sunlight.
PRODUCTS SPECS
PDF

Interface LVDS
Size 6.5
Touch Panel None
Brightness/Nits Range 700-999
Resolution

640 X 480

Module Size

153.0 x 118.0 x 11.9

Active Area

132.48 x 99.36

Polarizer Transmissive
Brightness/Nits 800
Viewing Direction 12:00

ASI-T-650MA4TN/D is a 6.5 inch TFT with a resolution of 800 x 480, RGB interface and with a brightness of 400 Nits

PRODUCTS SPECS
PDF
Interface RGB
Size 6.5
Touch Panel None
Brightness/Nits Range 400-699
Resolution 800 x 480
Module Size 155.20 x 89.40 x 5.5
Active Area 143.40 x 76.70
Polarizer Transmissive
Brightness/Nits 400
Viewing Direction 12:00

The ASI-T-650MA5AN/W is a 6.5" TFT with 800x480 resolution, RGB interface and 500 nits brightness.

PRODUCTS SPECS
PDF

Interface RGB
Size 6.5
Touch Panel None
Brightness/Nits Range 400-699
Resolution 800 X 480
Module Size

155.2 x 89.4 x 5.5

Active Area 143.4 x 76.704
Polarizer Transmissive
Brightness/Nits 500
Viewing Direction 12:00

The ASI-T-650MA8AN/W is a 6.5" TFT with 800x480 resolution, RGB interface and 800 nits brightness.

PRODUCTS SPECS
PDF

Interface RGB
Size 6.5
Touch Panel None
Brightness/Nits Range 700-999
Resolution 800 X 480
Module Size

155.2 x 89.4 x 5.5

Active Area 143.4 x 76.704
Polarizer Transmissive
Brightness/Nits 800
Viewing Direction 12:00

The ASI-T-6804812A4LN/D is a 6.86 inch TFT,  all view, LVDS/IPS interface, 480 x 1280 resolution and 450 nits brightness.

PRODUCTS SPECS
PDF
Interface LVDS
Size 6.86
Touch Panel None
Brightness/Nits Range 700-999
Resolution 480 x 1280
Module Size 66.80 x 181.00 x 4.5
Active Area 60.22 x 160.59
Polarizer Transmissive
Brightness/Nits 450
Viewing Direction IPS/All-view

ASI-T-6951A3M4/D is a 6.95 inch TFT with a resolution of 800 x 1280, IPS all view, MIPI interface, and a brightness of 300 Nits with a Capacitive Touch Panel.

PRODUCTS SPECS
PDF

Interface MIPI
Size 6.95
Touch Panel Capacitive Touch Panel
Brightness/Nits Range 100-399
Resolution 800 x 1280
Module Size

115.90 x 180.80 x 4.35

Active Area

94.20 x 150.72

Polarizer Transmissive
Brightness/Nits 300
Viewing Direction IPS/All-view

ASI-T-700JA12LPCAP/AE is a 7 inch TFT with a resolution of 1024 x 600, LVDS interface, IPS all view, a brightness of 1230 Nits with a Capacative Touch Panel.

PRODUCTS SPECS
PDF

Interface LVDS
Size 7
Touch Panel Capacitive Touch Panel
Brightness/Nits Range 1000 & up
Resolution 1024 x 600
Module Size

165.0 x 104.0 x 10.86

Active Area

154.214 x 85.92

Polarizer Transmissive
Brightness/Nits 1230
Viewing Direction IPS/All-view

ASI-T-700JA14LN/AE  is a 7 inch TFT with a resolution of 1024 x 600, LVDS interface, IPS all view, a brightness of 1400 Nits, ideal for outdoor viewing.

PRODUCTS SPECS
PDF

Interface LVDS
Size 7
Touch Panel None
Brightness/Nits Range 1000 & up
Resolution 1024 x 600
Module Size

165.0 x 104.0 x 9.31

Active Area

154.214 x 85.92

Polarizer Transmissive
Brightness/Nits 1400
Viewing Direction IPS/All-view

ASI-T-700JA3BP2/D is a 7 inch TFT with a resolution of 1024 x 600, RGB interface, a brightness of 320 Nits with a Capacative Touch Panel.

PRODUCTS SPECS
PDF

Interface RGB
Size 7
Touch Panel Capacitive Touch Panel
Brightness/Nits Range 100-399
Resolution 1024 x 600
Module Size

165.32 x 100.25 x 4.38

Active Area 154.21 x 85.92
Polarizer Transmissive
Brightness/Nits 320
Viewing Direction 12:00

ASI-T-700JA3BPN/D is a 7.0 inch TFT with a resolution of 1024 x 600, RGB interface and with a brightness of 380 Nits

PRODUCTS SPECS
PDF
Interface RGB
Size 7
Touch Panel None
Brightness/Nits Range 100-399
Resolution 1024 x 600
Module Size 164.90 x 100.00 x 2.8
Active Area 154.21 x 85.92
Polarizer Transmissive
Brightness/Nits 380
Viewing Direction 12:00

The ASI-T-700JA3HD6/A is a 7.0 inch TFT with HDMI interface, 1024 x 600 resolution, all-view with 340 nits and a capacitive touch panel.

PRODUCTS SPECS
PDF

Interface HDMI
Size 7
Touch Panel Capacitive Touch Panel
Brightness/Nits Range 100-399
Resolution 1024 x 600
Module Size

164.90 X 100.0 X 17.60

Active Area

154.21 X 85.92

Polarizer Transmissive
Brightness/Nits 340
Viewing Direction IPS/All-view

The ASI-T-700JA3HDR/A is a 7.0 inch TFT with HDMI interface, 1024 x 600 resolution, all-view with 310 nits and a resistive touch panel.

PRODUCTS SPECS
PDF

Interface HDMI
Size 7
Touch Panel Resistive Touch Panel
Brightness/Nits Range 100-399
Resolution 1024 x 600
Module Size

164.90 X 100.0 X 17.10

Active Area

154.21 X 85.92

Polarizer Transmissive
Brightness/Nits 310
Viewing Direction IPS/All-view

The ASI-T-700JA3L6/D is a 7.0" TFT with LVDS Interface, 1024x600 resolution, 380 nits and capacitive touch panel.

PRODUCTS SPECS
PDF

Interface LVDS
Size 7
Touch Panel Capacitive Touch Panel
Brightness/Nits Range 100-399
Resolution 1024 x 600
Module Size

165.06 x 100.32 x 4.68

Active Area 154.21 x 85.92
Polarizer Transmissive
Brightness/Nits 380
Viewing Direction 12:00

The ASI-T-700JA4HDN/A is a 7.0 inch TFT with HDMI interface, 1024 x 600 resolution, all-view and 400 nits brightness.

PRODUCTS SPECS
PDF

Interface HDMI
Size 7
Touch Panel None
Brightness/Nits Range 400-699
Resolution 1024 x 600
Module Size

164.90 X 100.0 X 15.60

Active Area

154.21 X 85.92

Polarizer Transmissive
Brightness/Nits 400
Viewing Direction IPS/All-view
The ASI-T-700JA5MP6/W is a 7.0 inch TFT with MIPI interface, 1024 x 600 resolution, all-view and 500 nits brightness and capacitive touch panel.
PRODUCTS SPECS
Active Area 154.21 X 85.92
Brightness/Nits 500
Brightness/Nits Range 400-699
Interface MIPI
Module Size 175.50 X 111.5 X 6.23
PDF

Polarizer Transmissive
Resolution 1024 x 600
Size 7
Touch Panel Capacitive Touch Panel
Viewing Direction IPS/All-view
$0.00

The ASI-T-700MA2HD6/D is a 7.0 inch TFT with HDMI interface, 800 x 480 resolution and a capacitive touch panel.

PRODUCTS SPECS
PDF

Interface HDMI
Size 7
Touch Panel Capacitive Touch Panel
Brightness/Nits Range 100-399
Resolution

800 x 480

Module Size

165.3 x 121 x 7.95

Active Area 154.21 x 85.92
Polarizer Transmissive
Brightness/Nits 250
Viewing Direction 12:00

ASI-T-700MA3DGT/D is a 7 inch TFT with a resolution of 800 x 480, Digital, Parallel 8-bit RGB interface, a brightness of 320 Nits with a Resistive Touch Panel.

PRODUCTS SPECS
PDF

Interface RGB
Size 7
Touch Panel Resistive Touch Panel
Brightness/Nits Range 100-399
Resolution 800X480
Module Size 164.9 x 100.0 x 7.1
Active Area 154.08 x 85.92
Polarizer Transmissive
Brightness/Nits 320
Viewing Direction

ASI-T-700MA3FT/D is a 7 inch TFT with a resolution of 800 x 480, Parallel 24-bit RGB interface, a brightness of 390 Nits with a Resistive Touch Panel.

PRODUCTS SPECS
PDF
Interface RGB
Size 7
Touch Panel Resistive Touch Panel
Brightness/Nits Range 100-399
Resolution 800 x 480
Module Size 164.9 x 100.0 x 4.45
Active Area 154.08 x 85.92
Polarizer Transmissive
Brightness/Nits 390
Viewing Direction 12:00

The ASI-T-700MA3HD6/A is a 7.0 inch TFT with HDMI interface, 800 x 480 resolution, 340 nits and a capacitive touch panel.

PRODUCTS SPECS
PDF

Interface HDMI
Size 7
Touch Panel Capacitive Touch Panel
Brightness/Nits Range 100-399
Resolution

800 x 480

Module Size

164.90 X 99.80 X 18.90

Active Area

154.08 X 85.92

Polarizer Transmissive
Brightness/Nits 340
Viewing Direction 12:00

The ASI-T-700MA3HDR/A is a 7.0 inch TFT with HDMI interface, 800 x 480 resolution, 320 nits and a Resistive touch panel.

PRODUCTS SPECS
PDF

Interface HDMI
Size 7
Touch Panel Resistive Touch Panel
Brightness/Nits Range 100-399
Resolution

800 x 480

Module Size

164.90 X 99.80 X 19.10

Active Area

154.08 X 85.92

Polarizer Transmissive
Brightness/Nits 320
Viewing Direction 12:00

ASI-T-700MA3T6/AF is a 7 inch TFT with a resolution of 800 x 480, TTL interface, a brightness of 300 Nits with a Capacitive Touch Panel.

PRODUCTS SPECS
PDF

Interface TTL
Size 7
Touch Panel Capacitive Touch Panel
Brightness/Nits Range 100-399
Resolution 800 x 480
Module Size

164.9 x 100.0 x 5.7

Active Area 154.08 x 85.92
Polarizer Transmissive
Brightness/Nits 300
Viewing Direction 12:00
