TFT Specifications

Wide Temperature TFT

ASI-T-17711A1FN/D is a 1.77 inch transflective TFT with a resolution of  160 x 128, 80-System 8/16-bit interface and with a brightness of  110 Nits; viewable in direct sunlight

PRODUCTS SPECS
PDF

Interface Other
Size 1.77
Touch Panel None
Brightness/Nits Range 100-399
Resolution 160 x 128
Module Size 40.77 x 36.20 x 2.20
Active Area 35.28 x 27.71
Polarizer Transflective
Brightness/Nits 110
Viewing Direction

ASI-T-240DA10SMN/AQ is a 2.4 inch high brightness TFT with a resolution of 240 x 320, SPI & MCU interface, IPS all-angle view and with a brightness of 1000 Nits; viewable in direct sunlight.  It also features an extra wide operating temperatures of -30 to +80C; perfect for extreme environmental applications.

PRODUCTS SPECS
PDF
Interface MCU, SPI
Size 2.4
Touch Panel None
Brightness/Nits Range 1000 & up
Resolution 240 x 320
Module Size 42.72 x 60.26 x 2.20
Active Area 36.72 x 48.96
Polarizer Transmissive
Brightness/Nits 1000
Viewing Direction IPS/All-view

ASI-T-350EA8RCY6/A is a 3.5 inch high brightness TFT with a resolution of 320 x 240, 24-bit Parallel RGB/Serial RGB/CCIR/YUV  interface and with a brightness of  850 Nits; viewable in direct sunlight with Capacitive Touch Panel

PRODUCTS SPECS
PDF

Interface RGB, Other
Size 3.5
Touch Panel Capacitive Touch Panel
Brightness/Nits Range 700-999
Resolution 320 X 240
Module Size

76.90 x 63.90 x 5.10

Active Area 70.08 x 52.56
Polarizer Transmissive
Brightness/Nits 850
Viewing Direction 12:00

ASI-T-430FA2F6/AY is a 4.3 inch IPS TFT with a resolution of 480 x 272, RGB interface, a brightness of 220 nits, wide operating temperature and a capacitive touch panel.

PRODUCTS SPECS
PDF

Interface RGB
Size 4.3
Touch Panel Capacitive Touch Panel
Brightness/Nits Range 100-399
Resolution 480 x 272
Module Size

105.42 x 67.07 x 3.0

Active Area 95.04 x 53.86
Polarizer Transmissive
Brightness/Nits 220
Viewing Direction IPS/All-view

ASI-T-430MA10FN/A is a 4.3 inch TFT with a resolution of 800 x 480, IPS all view, RGB interface, a brightness of 1000 Nits with a wide temperature operating and storage range.

PRODUCTS SPECS
PDF

Interface RGB
Size 4.3
Touch Panel None
Brightness/Nits Range 1000 & up
Resolution

800 x 480

Module Size

105.5 x 67.2 x 2.90

Active Area 95.04 x 53.86
Polarizer Transmissive
Brightness/Nits 1000
Viewing Direction IPS/All-view

ASI-T-500MA4F6/B is a 5.0 inch TFT with 24-bit RGB Interface, wide operating temperature, all-view and a capacitive touch panel.

PRODUCTS SPECS
PDF

Interface RGB
Size 5
Touch Panel Capacitive Touch Panel
Brightness/Nits Range 400-699
Resolution

800 x 480

Module Size

120.7 x 75.80 x 4.67

Active Area

108.00 x 64.80

Polarizer Transmissive
Brightness/Nits 480
Viewing Direction IPS/All-view
ASI-T-570GA3T2/D is a 5.7 inch TFT with a wide operating temperature, resolution of 640 X 480, RGB interface, a brightness of 360 Nits with a Capacitive Touch Panel.
PRODUCTS SPECS
PDF
Interface RGB
Size 5.7
Touch Panel Capacitive Touch Panel
Brightness/Nits Range 100-399
Resolution 640 X 480
Module Size 144.0 X 104.6 X 12.3
Active Area 115.2 X 86.4
Polarizer Transmissive
Brightness/Nits 360
Viewing Direction
ASI-T-570GA4TN/D is a 5.7 inch wide TFT, with a wide operating temperature and a resolution of 640 x 480, RGB interface and a brightness of 400 Nits.
PRODUCTS SPECS
PDF
Interface RGB
Size 5.7
Touch Panel None
Brightness/Nits Range 400-699
Resolution 640 x 480
Module Size 144.00 x 104.60 x 12.30
Active Area 115.20 x 86.40
Polarizer Transmissive
Brightness/Nits 400
Viewing Direction 6:00

ASI-T-700MA4DN/D is a 7 inch wide TFT, with a wide operating temperature and a resolution of 800 x 480, RGB interface and a brightness of 400 Nits.

PRODUCTS SPECS
PDF
Interface RGB
Size 7
Touch Panel None
Brightness/Nits Range 400-699
Resolution 800 x 480
Module Size 164.90 x 100.00 x 5.7
Active Area 154.08 x 85.92
Polarizer Transmissive
Brightness/Nits 400
Viewing Direction 12:00

ASI-T-700MA5AN/D is a 7 inch wide TFT, with a wide operating temperature and a resolution of 800 x 480, RGB interface and a brightness of 500 Nits.

PRODUCTS SPECS
PDF
Interface RGB
Size 7
Touch Panel None
Brightness/Nits Range 400-699
Resolution 800 x 480
Module Size 164.90 x 100.00 x 5.7
Active Area 154.08 x 85.92
Polarizer Transmissive
Brightness/Nits 500
Viewing Direction 12:00

ASI-T-700MAKFN/A is an industrial grade, high reliability, 7 inch  TFT with a resolution of 800 x 480, 24-bit RGB interface, wide temperature range, IPS all view and with a high brightness of 1000 Nits; viewable in direct sunlight.

PRODUCTS SPECS
PDF

Interface RGB
Size 7
Touch Panel None
Brightness/Nits Range 1000 & up
Resolution 800 x 480
Module Size

165.0 x 104.0 x 8.4

Active Area

152.40 x 91.44

Polarizer Transmissive
Brightness/Nits 1000
Viewing Direction IPS/All-view

ASI-T-800JA5LN/D is a 8 inch wide high brightness TFT, with a wide operating temperature and a resolution of 1024 x 600, LVDS interface and a brightness of 500 Nits.

PRODUCTS SPECS
PDF
Interface LVDS
Size 8
Touch Panel None
Brightness/Nits Range 400-699
Resolution 1024 x 600
Module Size 192.80 x 116.90 X 6.4
Active Area 176.64 x 99.36
Polarizer Transmissive
Brightness/Nits 500
Viewing Direction 12:00

ASI-T-800MA4NN/D is a 8 inch wide TFT, with a wide operating temperature and a resolution of 800 x 480, RGB interface and a brightness of 450 Nits.

PRODUCTS SPECS
PDF
Interface RGB
Size 8
Touch Panel None
Brightness/Nits Range 400-699
Resolution 800 x 480
Module Size 192.8 x 116.9 x 6.4
Active Area 176.64 x 99.36
Polarizer Transmissive
Brightness/Nits 450
Viewing Direction

The ASI-T-800SAAKLN/A is a 8.0 inch TFT 4-lane LVDS interface, full viewing angle, 1280 x 720 resolution and 1000 nits brightness.

PRODUCTS SPECS
PDF

Interface LVDS
Size 8
Touch Panel None
Brightness/Nits Range 1000 & up
Resolution

1280 X 720

Module Size

192.80 x 116.90 x 9.85

Active Area

176.64 x 99.36

Polarizer Transmissive
Brightness/Nits 1000
Viewing Direction IPS/All-view

ASI-T-9201948A5LN/D is a 9.2 inch wide TFT, with a wide operating temperature and a resolution of 1920 x 480, LVDS - Bar Type interface and a brightness of 500 Nits; viewable in direct sunlight.

PRODUCTS SPECS
PDF
Interface LVDS
Size 9.2
Touch Panel None
Brightness/Nits Range 400-699
Resolution 1920 x 480
Module Size 237.00 x 72.30 x 5.8
Active Area 226.94 x 56.74
Polarizer Transmissive
Brightness/Nits 500
Viewing Direction

ASI-T-1020MA3NN/D is a 10.2 inch wide TFT, with a resolution of 800 x 480, RGB interface and a brightness of 350 Nits.

PRODUCTS SPECS
PDF
Interface RGB
Size 10.2
Touch Panel None
Brightness/Nits Range 100-399
Resolution 800 x 480
Module Size 235.0 x 145.8 x 5.5
Active Area 222.00 x 132.48
Polarizer Transmissive
Brightness/Nits 350
Viewing Direction

ASI-T-10251248AKLN/D is a 10.25 inch wide TFT, with a resolution of 1280 x 480, LVDS interface, IPS all view, with wide temperature operation and storage and a high brightness of 1,000 Nits.

PRODUCTS SPECS
PDF

Interface LVDS
Size 10.25
Touch Panel None
Brightness/Nits Range 1000 & up
Resolution

1280 x 480

Module Size

258.60 x 107.00 x 6.31

Active Area

243.84 x 91.44

Polarizer Transmissive
Brightness/Nits 1000
Viewing Direction IPS/All-view

ASI-T-1040GA6TN/D is a 10.4 inch wide TFT, with a wide operating temperature and a resolution of 640 x 480, All View display, RGB interface and a brightness of 500 Nits.

PRODUCTS SPECS
PDF
Interface RGB
Size 10.4
Touch Panel None
Brightness/Nits Range 400-699
Resolution 640 x 480
Module Size 225.50 x 176.30 x 7.81
Active Area 211.20 x 158.40
Polarizer Transmissive
Brightness/Nits 500
Viewing Direction IPS/All-view

ASI-T-1040HB4LN/D is a 10.4 inch wide TFT, with a wide operating temperature and a resolution of 800 x 600, LVDS interface and a brightness of 400 Nits.

PRODUCTS SPECS
PDF
Interface LVDS
Size 10.4
Touch Panel None
Brightness/Nits Range 400-699
Resolution 800 x 600
Module Size 243.00 x 179.40 x 8.5
Active Area 211.20 x 158.40
Polarizer Transmissive
Brightness/Nits 400
Viewing Direction 6:00

ASI-T-1210HB4LN/D is a 12.1 inch wide TFT, with a wide operating temperature, a resolution of 800 x 600, all view display, LVDS interface and a brightness of 450 Nits.

PRODUCTS SPECS
PDF
Interface LVDS
Size 12.1
Touch Panel None
Brightness/Nits Range 400-699
Resolution 800 x 600
Module Size 260.50 x 204.00 x 8.4
Active Area 246.00 x 184.50
Polarizer Transmissive
Brightness/Nits 450
Viewing Direction IPS/All-view
