HDMI Interface TFT

ASI-T-500MB6HDN/A is a 5.0 inch TFT with a resolution of 800 x 480, HDMI interface and with a high brightness of 600 Nits, viewable in direct sunlight.

PRODUCTS SPECS
Size 5
Resolution 800 x 480
Module Size 120.7 x 75.8 x 3.00
Active Area 108.0 x 64.80
Interface HDMI
Touch Panel None
Brightness/Nits Range 400-699
Brightness/Nits 600
PDF
Polarizer Transmissive
Viewing Direction 12:00

The ASI-T-700JA3HD6/A is a 7.0 inch TFT with HDMI interface, 1024 x 600 resolution, all-view with 340 nits and a capacitive touch panel.

PRODUCTS SPECS
Size 7
Resolution 1024 x 600
Module Size

164.90 X 100.0 X 20.10

Active Area

154.21 X 85.92

Interface HDMI
Touch Panel Capacitive Touch Panel
Brightness/Nits Range 100-399
Brightness/Nits 340
PDF

Polarizer Transmissive
Viewing Direction IPS/All-view

The ASI-T-700JA3HDR/A is a 7.0 inch TFT with HDMI interface, 1024 x 600 resolution, all-view with 310 nits and a resistive touch panel.

PRODUCTS SPECS
Size 7
Resolution 1024 x 600
Module Size

164.90 X 100.0 X 17.10

Active Area

154.21 X 85.92

Interface HDMI
Touch Panel Resistive Touch Panel
Brightness/Nits Range 100-399
Brightness/Nits 310
PDF

Polarizer Transmissive
Viewing Direction IPS/All-view

The ASI-T-700JA4HDN/A is a 7.0 inch TFT with HDMI interface, 1024 x 600 resolution, all-view and 400 nits brightness.

PRODUCTS SPECS
Size 7
Resolution 1024 x 600
Module Size

164.90 X 100.0 X 18.10

Active Area

154.21 X 85.92

Interface HDMI
Touch Panel None
Brightness/Nits Range 400-699
Brightness/Nits 400
PDF

Polarizer Transmissive
Viewing Direction IPS/All-view

The ASI-T-700MA2HD6/D is a 7.0 inch TFT with HDMI interface, 800 x 480 resolution and a capacitive touch panel.

PRODUCTS SPECS
Size 7
Resolution

800 x 480

Module Size

165.3 x 121 x 7.95

Active Area 154.21 x 85.92
Interface HDMI
Touch Panel Capacitive Touch Panel
Brightness/Nits Range 100-399
Brightness/Nits 250
PDF

Polarizer Transmissive
Viewing Direction 12:00

The ASI-T-700MA3HD6/A is a 7.0 inch TFT with HDMI interface, 800 x 480 resolution, 340 nits and a capacitive touch panel.

PRODUCTS SPECS
Size 7
Resolution

800 x 480

Module Size

164.90 X 99.80 X 18.90

Active Area

154.08 X 85.92

Interface HDMI
Touch Panel Capacitive Touch Panel
Brightness/Nits Range 100-399
Brightness/Nits 340
PDF

Polarizer Transmissive
Viewing Direction 12:00

The ASI-T-700MA3HDR/A is a 7.0 inch TFT with HDMI interface, 800 x 480 resolution, 320 nits and a Resistive touch panel.

PRODUCTS SPECS
Size 7
Resolution

800 x 480

Module Size

164.90 X 99.80 X 10.60

Active Area

154.08 X 85.92

Interface HDMI
Touch Panel Resistive Touch Panel
Brightness/Nits Range 100-399
Brightness/Nits 320
PDF

Polarizer Transmissive
Viewing Direction 12:00

The ASI-T-700MA3HUR/A is a 7.0 inch TFT with HDMI interface, 800 x 480 resolution, 320 nits and a Resistive touch panel.

PRODUCTS SPECS
Size 7
Resolution

800 x 480

Module Size

181.50 x 100.60 x 11.20

Active Area

154.08 X 85.92

Interface HDMI
Touch Panel Resistive Touch Panel
Brightness/Nits Range 100-399
Brightness/Nits 320
PDF

Polarizer Transmissive
Viewing Direction 12:00

The ASI-T-700MA4HDN/A is a 7.0 inch TFT with HDMI interface, 800 x 480 resolution and 420 nits brightness.

PRODUCTS SPECS
Size 7
Resolution

800 x 480

Module Size

164.90 X 99.80 X 17.60

Active Area

154.08 X 85.92

Interface HDMI
Touch Panel None
Brightness/Nits Range 400-699
Brightness/Nits 420
PDF

Polarizer Transmissive
Viewing Direction 12:00

ASI-T-700MB4FHDN/A is a 7 inch TFT with a resolution of 800 x 480, HDMI interface, and a brightness of 420 Nits.

PRODUCTS SPECS
Size 7
Resolution 800 x 480
Module Size

181,60 x 100.60 x 9.70

Active Area

154.08 x 85.92

Interface HDMI
Touch Panel None
Brightness/Nits Range 400-699
Brightness/Nits 420
PDF

Polarizer Transmissive
Viewing Direction 12:00

ASI-T-1010SA8HU6/A is a 10.1 inch high brightness TFT with a resolution of 1280 x 800, All-View, HDMI & USB interface, with a brightness of 850 Nits; viewable in direct sunlight and a capacitive touch panel.

PRODUCTS SPECS
Size 10.1
Resolution 1280 x 800
Module Size 240.00 x 165.00 x 20.90
Active Area 216.96 x 135.60
Interface HDMI, Other
Touch Panel Capacitive Touch Panel
Brightness/Nits Range 700-999
Brightness/Nits 850
PDF
Polarizer Transmissive
Viewing Direction IPS/All-view

ASI-T-1010SA9HD6/X is a 10.1 inch high brightness TFT with a resolution of 1280 x 800, IPS all-view,  HDMI interface and with a brightness of 900 Nits; viewable in direct sunlight with Capacitive Touch Panel

PRODUCTS SPECS
Size 10.1
Resolution 1280 x 800
Module Size

257.96 x 168.6 x 28.2

Active Area 216.96 x 135.60
Interface HDMI
Touch Panel Capacitive Touch Panel
Brightness/Nits Range 700-999
Brightness/Nits 900
PDF

Polarizer Transmissive
Viewing Direction IPS/All-view
