Sunlight Viewable TFT

ASI-T-17711A1FN/D is a 1.77 inch transflective TFT with a resolution of  160 x 128, 80-System 8/16-bit interface and with a brightness of  110 Nits; viewable in direct sunlight

PRODUCTS SPECS
PDF

Interface Other
Size 1.77
Touch Panel None
Brightness/Nits Range 100-399
Resolution 160 x 128
Module Size 40.77 x 36.20 x 2.20
Active Area 35.28 x 27.71
Polarizer Transflective
Brightness/Nits 110
Viewing Direction

ASI-T-20043A5PMN/AY is a 2.0 inch TFT with a resolution of 480 x 360, 3W SPI+16 bit RGB or MIPI interface, IPS all view, with a high brightness of 500 Nits.

PRODUCTS SPECS
PDF

Interface MIPI, RGB, SPI
Size 2
Touch Panel None
Brightness/Nits Range 400-699
Resolution 480 x 360
Module Size 46.16 x 40.97 x 2.4
Active Area 40.824 x 30.618
Polarizer Transmissive
Brightness/Nits 500
Viewing Direction IPS/All-view

ASI-T-200EA6SRN/D is a 2.0 inch IPS TFT with a resolution of  320 x 240, SPI or RGB  interface, contrast of 1,500 and a brightness of 620 Nits.

PRODUCTS SPECS
PDF

Interface RGB, SPI
Size 2
Touch Panel None
Brightness/Nits Range 400-699
Resolution 320 X 240
Module Size 46.10 x 40.96 x 2.54
Active Area 40.8 x 30.6
Polarizer Transmissive
Brightness/Nits 620
Viewing Direction IPS/All-view

ASI-T-2201DA0EN/W is a 2.2 inch TFT with a resolution of 240 x 320, RGB interface and with a brightness of  90 Nits; Transflective - viewable in direct sunlight.

PRODUCTS SPECS
PDF
Interface RGB
Size 2.2
Touch Panel None
Brightness/Nits Range 0-99
Resolution 240 x 320
Module Size 40.6 x 56.6 x 2.7
Active Area 33.84 x 45.12
Polarizer Transflective
Brightness/Nits 90
Viewing Direction 12:00
ASI-T-240DA8BN/D is a 2.4 inch high brightness TFT with a resolution of 240 X 320, CPU 16-bit interface and with a brightness of 800 Nits; viewable in direct sunlight.
PRODUCTS SPECS
PDF

Interface CPU
Size 2.4
Touch Panel None
Brightness/Nits Range 700-999
Resolution 240 x 320
Module Size 42.72 x 59.4 x 2.15
Active Area 36.72 x 48.96
Polarizer Transmissive
Brightness/Nits 800
Viewing Direction 6:00

ASI-T-240DA10SMN/AQ is a 2.4 inch high brightness TFT with a resolution of 240 x 320, SPI & MCU interface, IPS all-angle view and with a brightness of 1000 Nits; viewable in direct sunlight.  It also features an extra wide operating temperatures of -30 to +80C; perfect for extreme environmental applications.

PRODUCTS SPECS
PDF
Interface MCU, SPI
Size 2.4
Touch Panel None
Brightness/Nits Range 1000 & up
Resolution 240 x 320
Module Size 42.72 x 60.26 x 2.20
Active Area 36.72 x 48.96
Polarizer Transmissive
Brightness/Nits 1000
Viewing Direction IPS/All-view

ASI-T-240DAKBN/D is a 2.4 inch high brightness TFT with a resolution of 240 x 320, MCU interface and with a brightness of 1000 Nits; viewable in direct sunlight.

PRODUCTS SPECS
PDF
Interface MCU
Size 2.4
Touch Panel None
Brightness/Nits Range 1000 & up
Resolution 240 x 320
Module Size 42.72 x 60.35 x 2.90
Active Area 36.72 x 48.96
Polarizer Transmissive
Brightness/Nits 1000
Viewing Direction 6:00

ASI-T-283DAKCRN/A is a 2.83 inch high brightness TFT with a resolution of 240 x 320, CPU, RGB, SPI  interface and with a brightness of  1000 Nits; viewable in direct sunlight

PRODUCTS SPECS
PDF

Interface CPU, RGB, SPI
Size 2.83
Touch Panel None
Brightness/Nits Range 1000 & up
Resolution 240 x 320
Module Size 50.20 x 69.30 x 2.9
Active Area 43.2 x 57.60
Polarizer Transmissive
Brightness/Nits 1000
Viewing Direction 6:00

ASI-T-283DB5SRN/A  is a 2.83 inch IPS, all-view TFT  with a resolution of 240 x 320, RGB & SPI  interface and with a brightness of  500 Nits.

PRODUCTS SPECS
PDF

Interface RGB, SPI
Size 2.83
Touch Panel None
Brightness/Nits Range 400-699
Resolution 240 x 320
Module Size 50.50 x 69.70 x 2.6
Active Area 43.2 x 57.60
Polarizer Transmissive
Brightness/Nits 500
Viewing Direction IPS/All-view

ASI-T-3501RA1EN/A is a 3.5 inch TFT with a resolution of 480 x 640, 18 bit RGB, All View interface and with a brightness of 120 Nits; viewable in direct sunlight

PRODUCTS SPECS
PDF

Interface RGB
Size 3.5
Touch Panel None
Brightness/Nits Range 100-399
Resolution 480 x 640
Module Size

64.00 x 85.00 x 3.10

Active Area

53.568 x 71.424

Polarizer Transflective
Brightness/Nits 120
Viewing Direction IPS/All-view

ASI-T-3501RA1EN/D is a 3.5 inch TFT with a resolution of 480 x 640, 18-bit DBI Type B, All View interface and with a brightness of  120 Nits; viewable in direct sunlight

PRODUCTS SPECS
PDF

Interface RGB
Size 3.5
Touch Panel None
Brightness/Nits Range 100-399
Resolution 480 x 640
Module Size

64.00 x 85.00 x 3.10

Active Area

53.568 x 71.424

Polarizer Transflective
Brightness/Nits 120
Viewing Direction IPS/All-view

ASI-T-350EA8RCY6/A is a 3.5 inch high brightness TFT with a resolution of 320 x 240, 24-bit Parallel RGB/Serial RGB/CCIR/YUV  interface and with a brightness of  850 Nits; viewable in direct sunlight with Capacitive Touch Panel

PRODUCTS SPECS
PDF

Interface RGB, Other
Size 3.5
Touch Panel Capacitive Touch Panel
Brightness/Nits Range 700-999
Resolution 320 X 240
Module Size

76.90 x 63.90 x 5.10

Active Area 70.08 x 52.56
Polarizer Transmissive
Brightness/Nits 850
Viewing Direction 12:00

ASI-T-350EB6FN/D is a 3.5 inch high brightness TFT with a resolution of 320 x 240, RBG 24 bits interface and with a brightness of 600 Nits; viewable in direct sunlight.

PRODUCTS SPECS
PDF

Interface RGB
Size 3.5
Touch Panel None
Brightness/Nits Range 400-699
Resolution 320 x 240
Module Size 76.8 x 63.8 x 3.1
Active Area 70.08 x 52.56
Polarizer Transmissive
Brightness/Nits 600
Viewing Direction 6:00

ASI-T-350ZA5SRN/AC is a 3.5 inch high brightness TFT with a resolution of 320 X 480, SPI+RGB interface, IPS, a brightness of 550 Nits; viewable in direct sunlight

PRODUCTS SPECS
PDF

Interface RGB, SPI
Size 3.5
Touch Panel None
Brightness/Nits Range 400-699
Resolution

320 x 480

Module Size

53.76 x 84.18 x 2.15

Active Area

48.96 x 73.44

Polarizer Transmissive
Brightness/Nits 550
Viewing Direction IPS/All-view

ASI-T-39548A6SRN/AY is a 3.95 inch high brightness TFT with a resolution of 480 x 480, SPI/RGB interface and with a brightness of 650 Nits; viewable in direct sunlight

PRODUCTS SPECS
PDF

Interface RGB, SPI
Size 3.95
Touch Panel None
Brightness/Nits Range 400-699
Resolution

480 X 480

Module Size

74.83 x 78.98 x 2.0

Active Area

71.856 x 70.176

Polarizer Transmissive
Brightness/Nits 650
Viewing Direction IPS/All-view

ASI-T-397NA8M6/AT is a 3.97 inch high brightness TFT with a resolution of 480 x 800, MIPI interface and with a brightness of 850 Nits; viewable in direct sunlight with Capacitive Touch Panel

PRODUCTS SPECS
PDF

Interface MIPI
Size 3.97
Touch Panel Capacitive Touch Panel
Brightness/Nits Range 700-999
Resolution

480 X 800

Module Size

62.5 x 111.02 x 3.465

Active Area

51.84 X 86.4

Polarizer Transmissive
Brightness/Nits 850
Viewing Direction 6:00

ASI-T-4001QA2AN/D is a 4.0 inch TFT with a resolution of 360 x 600, RGB/MCU interface and with a brightness of 200 Nits; viewable in direct sunlight

PRODUCTS SPECS
PDF

Interface MCU, RGB
Size 4
Touch Panel None
Brightness/Nits Range 100-399
Resolution

360 X 600

Module Size

60.04 x 102.8 x 2.8

Active Area

51.84 x 86.4

Polarizer Transflective
Brightness/Nits 200
Viewing Direction 6:00

ASI-T-430FA13FN/A is a 4.3 inch high brightness TFT with a resolution of 480 x 272, RGB interface and with a brightness of 1300 Nits; viewable in direct sunlight.

PRODUCTS SPECS
PDF

Interface RGB
Size 4.3
Touch Panel None
Brightness/Nits Range 1000 & up
Resolution 480 x 272
Module Size

105.5 x 67.2 x 3.0

Active Area

95.04 x 53.856

Polarizer Transmissive
Brightness/Nits 1300
Viewing Direction 12:00

ASI-T-430FA6AN/D is a 4.3 inch high brightness TFT with a resolution of 480 X 272, RGB interface and with a brightness of 650 Nits; viewable in direct sunlight.

PRODUCTS SPECS
PDF
Interface RGB
Size 4.3
Touch Panel None
Brightness/Nits Range 400-699
Resolution 480 X 272
Module Size 105.4 X 67.10 X 4.10
Active Area 95.04 X 53.86
Polarizer Transmissive
Brightness/Nits 650
Viewing Direction

ASI-T-430FAKFN/D is a 4.3 inch high brightness TFT with a resolution of 480 X 272, RGB interface and with a brightness of 1000 Nits; viewable in direct sunlight.

PRODUCTS SPECS
PDF

Interface RGB
Size 4.3
Touch Panel None
Brightness/Nits Range 1000 & up
Resolution 480 X 272
Module Size 105.5 x 67.2 x 3.0
Active Area 95.04 x 53.86
Polarizer Transmissive
Brightness/Nits 1000
Viewing Direction 12:00

ASI-T-430MA10FN/A is a 4.3 inch TFT with a resolution of 800 x 480, IPS all view, RGB interface, a brightness of 1000 Nits with a wide temperature operating and storage range.

PRODUCTS SPECS
PDF

Interface RGB
Size 4.3
Touch Panel None
Brightness/Nits Range 1000 & up
Resolution

800 x 480

Module Size

105.5 x 67.2 x 2.90

Active Area 95.04 x 53.86
Polarizer Transmissive
Brightness/Nits 1000
Viewing Direction IPS/All-view

ASI-T-500MA6F5/D is a 5 inch high brightness TFT with a resolution of 800 x 480, RGB interface and with a brightness of 690 Nits; viewable in direct sunlight with Capacitive Touch Panel

PRODUCTS SPECS
PDF
Interface RGB
Size 5
Touch Panel Capacitive Touch Panel
Brightness/Nits Range 400-699
Resolution 800 x 480
Module Size 121.1 x 76.2 x 5.0
Active Area 108.0 x 64.8
Polarizer Transmissive
Brightness/Nits 690
Viewing Direction 12:00

ASI-T-500MA8AN/D is a 5 inch high brightness TFT with a resolution of 800 x 480, RGB interface and with a brightness of 800 Nits; viewable in direct sunlight.

PRODUCTS SPECS
PDF
Interface RGB
Size 5
Touch Panel None
Brightness/Nits Range 700-999
Resolution 800 x 480
Module Size 120.7 x 75.8 x 3.1
Active Area 108.0 x 64.080
Polarizer Transmissive
Brightness/Nits 800
Viewing Direction 12:00
ASI-T-560GA8AN/D is a 5.6 inch high brightness TFT with a resolution of 640 x 480, RGB interface and with a brightness of 800 Nits; viewable in direct sunlight.
PRODUCTS SPECS
PDF

Interface RGB
Size 5.6
Touch Panel None
Brightness/Nits Range 700-999
Resolution 640 x 480
Module Size 126.50 x 100.00 x 5.7
Active Area 112.89 x 84.67
Polarizer Transmissive
Brightness/Nits 800
Viewing Direction 12:00

ASI-T-570EA14QN/D is a 5.7 inch high brightness TFT with a resolution of 320 x 240, 8-bit parallel / serial interface and with a brightness of 1400 Nits; viewable in direct sunlight.

PRODUCTS SPECS
PDF
Interface Other
Size 5.7
Touch Panel None
Brightness/Nits Range 1000 & up
Resolution 320 x 240
Module Size 159.5 x 108.4 x 6.35
Active Area 115.2 x 86.4
Polarizer Transmissive
Brightness/Nits 1400
Viewing Direction 6:00

ASI-T-570EA6TT/D is a 5.7 inch high brightness TFT with a resolution of 320 x 240, TTL interface and with a brightness of 650 Nits; viewable in direct sunlight with Resistive Touch Panel

PRODUCTS SPECS
PDF
Interface Other
Size 5.7
Touch Panel Resistive Touch Panel
Brightness/Nits Range 400-699
Resolution 320 x 240
Module Size 127.0 x 98.43 x 10.5
Active Area 115.2 x 86.4
Polarizer Transmissive
Brightness/Nits 650
Viewing Direction

ASI-T-570EA8TN/D is a 5.7 inch high brightness TFT with a resolution of 320 x 240, TTL interface and with a brightness of 800 Nits; viewable in direct sunlight.

PRODUCTS SPECS
PDF
Interface Other
Size 5.7
Touch Panel None
Brightness/Nits Range 700-999
Resolution 320 x 240
Module Size 127 x 98.43 x 9.2
Active Area 115.2 x 86.4
Polarizer Transmissive
Brightness/Nits 800
Viewing Direction

ASI-T-570GA8A2/D is a 5.7 inch high brightness TFT with a resolution of 640 x 480, RGB interface and with a brightness of 810 Nits; viewable in direct sunlight with Capacative Touch Panel

PRODUCTS SPECS
PDF
Interface RGB
Size 5.7
Touch Panel Capacitive Touch Panel
Brightness/Nits Range 700-999
Resolution 640 x 480
Module Size 127.0 x 100 x 8.56
Active Area 115.2 x 86.4
Polarizer Transmissive
Brightness/Nits 810
Viewing Direction 12:00

ASI-T-570GA8AN/D is a 5.7 inch high brightness TFT with a resolution of 640 X 480, RGB interface and with a brightness of 900 Nits; viewable in direct sunlight.

PRODUCTS SPECS
PDF
Interface RGB
Size 5.7
Touch Panel None
Brightness/Nits Range 700-999
Resolution 640 X 480
Module Size 127.0 x 98.43 x 7.0
Active Area 115.2 X 86.4
Polarizer Transmissive
Brightness/Nits 900
Viewing Direction 12:00
ASI-T-650GA8LN/D is a 6.5 inch high brightness TFT with a resolution of 640 X 480, LVDS interface and with a brightness of 800 Nits; viewable in direct sunlight.
PRODUCTS SPECS
PDF

Interface LVDS
Size 6.5
Touch Panel None
Brightness/Nits Range 700-999
Resolution

640 X 480

Module Size

153.0 x 118.0 x 11.9

Active Area

132.48 x 99.36

Polarizer Transmissive
Brightness/Nits 800
Viewing Direction 12:00

The ASI-T-650MA8AN/W is a 6.5" TFT with 800x480 resolution, RGB interface and 800 nits brightness.

PRODUCTS SPECS
PDF

Interface RGB
Size 6.5
Touch Panel None
Brightness/Nits Range 700-999
Resolution 800 X 480
Module Size

155.2 x 89.4 x 5.5

Active Area 143.4 x 76.704
Polarizer Transmissive
Brightness/Nits 800
Viewing Direction 12:00

ASI-T-700JA12LPCAP/AE is a 7 inch TFT with a resolution of 1024 x 600, LVDS interface, IPS all view, a brightness of 1230 Nits with a Capacative Touch Panel.

PRODUCTS SPECS
PDF

Interface LVDS
Size 7
Touch Panel Capacitive Touch Panel
Brightness/Nits Range 1000 & up
Resolution 1024 x 600
Module Size

165.0 x 104.0 x 10.86

Active Area

154.214 x 85.92

Polarizer Transmissive
Brightness/Nits 1230
Viewing Direction IPS/All-view

ASI-T-700JA14LN/AE  is a 7 inch TFT with a resolution of 1024 x 600, LVDS interface, IPS all view, a brightness of 1400 Nits, ideal for outdoor viewing.

PRODUCTS SPECS
PDF

Interface LVDS
Size 7
Touch Panel None
Brightness/Nits Range 1000 & up
Resolution 1024 x 600
Module Size

165.0 x 104.0 x 9.31

Active Area

154.214 x 85.92

Polarizer Transmissive
Brightness/Nits 1400
Viewing Direction IPS/All-view
ASI-T-700MA8LN/D is a 7 inch high brightness TFT with a resolution of 800 x 480, LVDS interface and with a brightness of 800 Nits; viewable in direct sunlight.
PRODUCTS SPECS
PDF

Interface LVDS
Size 7
Touch Panel None
Brightness/Nits Range 700-999
Resolution 800 x 480
Module Size

165.0 x 100.0 x 6.9

Active Area 154.08 x 85.92
Polarizer Transmissive
Brightness/Nits 800
Viewing Direction 12:00

ASI-T-700MAKFN/A is an industrial grade, high reliability, 7 inch  TFT with a resolution of 800 x 480, 24-bit RGB interface, wide temperature range, IPS all view and with a high brightness of 1000 Nits; viewable in direct sunlight.

PRODUCTS SPECS
PDF

Interface RGB
Size 7
Touch Panel None
Brightness/Nits Range 1000 & up
Resolution 800 x 480
Module Size

165.0 x 104.0 x 8.4

Active Area

152.40 x 91.44

Polarizer Transmissive
Brightness/Nits 1000
Viewing Direction IPS/All-view

ASI-T-7844128A8LN/A is a 7.84 inch high brightness TFT with a resolution of 400 x 1280, LVDS, All View, Bar Type interface and with a brightness of 850 Nits; viewable in direct sunlight.

PRODUCTS SPECS
PDF

Interface LVDS
Size 7.84
Touch Panel None
Brightness/Nits Range 700-999
Resolution 400 x 1280
Module Size

67.60 x 205.78 x 7.5

Active Area 59.40 x 190.08
Polarizer Transmissive
Brightness/Nits 850
Viewing Direction IPS/All-view

ASI-T-7844128A8LN/D is a 7.84 inch high brightness TFT with a resolution of 400 x 1280, LVDS/IPS interface and with a brightness of 550~850; viewable in direct sunlight.

PRODUCTS SPECS
PDF
Interface LVDS
Size 7.84
Touch Panel None
Brightness/Nits Range 700-999
Resolution 400 x 1280
Module Size 70.6 x 203.48 x 4.60
Active Area 59.4 x 190.08
Polarizer Transmissive
Brightness/Nits 850
Viewing Direction IPS/All-view

The ASI-T-800SAAKLN/A is a 8.0 inch TFT 4-lane LVDS interface, full viewing angle, 1280 x 720 resolution and 1000 nits brightness.

PRODUCTS SPECS
PDF

Interface LVDS
Size 8
Touch Panel None
Brightness/Nits Range 1000 & up
Resolution

1280 X 720

Module Size

192.80 x 116.90 x 9.85

Active Area

176.64 x 99.36

Polarizer Transmissive
Brightness/Nits 1000
Viewing Direction IPS/All-view

ASI-T-1010SA9HD6/X is a 10.1 inch high brightness TFT with a resolution of 1280 x 800, IPS,  HDMI interface and with a brightness of 900 Nits; viewable in direct sunlight with Capacitive Touch Panel

PRODUCTS SPECS
PDF

Interface HDMI
Size 10.1
Touch Panel Capacitive Touch Panel
Brightness/Nits Range 700-999
Resolution 1280 x 800
Module Size

257.96 x 168.6 x 28.2

Active Area 216.96 x 135.60
Polarizer Transmissive
Brightness/Nits 900
Viewing Direction IPS/All-view

ASI-T-10251248AKLN/D is a 10.25 inch wide TFT, with a resolution of 1280 x 480, LVDS interface, IPS all view, with wide temperature operation and storage and a high brightness of 1,000 Nits.

PRODUCTS SPECS
PDF

Interface LVDS
Size 10.25
Touch Panel None
Brightness/Nits Range 1000 & up
Resolution

1280 x 480

Module Size

258.60 x 107.00 x 6.31

Active Area

243.84 x 91.44

Polarizer Transmissive
Brightness/Nits 1000
Viewing Direction IPS/All-view
