ASI-T-1302A10SPN/A is a 1.3 inch all-view TFT display with a resolution of 240 x 240, SPI interface, and a high brightness of 1000 Nits, ideal for outdoor viewing.
ASI-T-240DA10SMN/AQ is a 2.4 inch high brightness TFT with a resolution of 240 x 320, SPI & MCU interface, IPS all-angle view and with a brightness of 1000 Nits; viewable in direct sunlight. It also features an extra wide operating temperatures of -30 to +80C; perfect for extreme environmental applications.
ASI-T-240DAKBN/D is a 2.4 inch high brightness TFT with a resolution of 240 x 320, MCU interface and with a brightness of 1000 Nits; viewable in direct sunlight.
ASI-T-283DAKCRN/A is a 2.83 inch high brightness TFT with a resolution of 240 x 320, CPU, RGB, SPI interface and with a brightness of 1000 Nits; viewable in direct sunlight
ASI-T-350EA10SRN/A is a 3.5 inch TFT with a resolution of 320 x 240, SPI & RGB interface and with a high brightness of 1,000 Nits and wide temperature range of -30 - +85 C.
ASI-T-350ZA10RMN/AY is a 3.5 inch TFT with a resolution of 320 x 480, RGB & MCU interface and with a high brightness of 1000 nits, readable in direct sunlight.
320 x 480
54.48 x 84.71 x 2.25
48.96 x 73.44
ASI-T-430FA13FN/A is a 4.3 inch high brightness TFT with a resolution of 480 x 272, RGB interface and with a brightness of 1300 Nits; viewable in direct sunlight.
105.5 x 67.2 x 3.0
95.04 x 53.856
ASI-T-430FAKFN/D is a 4.3 inch high brightness TFT with a resolution of 480 X 272, RGB interface and with a brightness of 1000 Nits; viewable in direct sunlight.
ASI-T-430MA10FN/A is a 4.3 inch TFT with a resolution of 800 x 480, IPS all view, RGB interface, a brightness of 1000 Nits with an ultra wide temperature operating and storage range.
800 x 480
105.5 x 67.2 x 2.90
ASI-T-700JA12LPCAP/AE is a 7 inch TFT with a resolution of 1024 x 600, LVDS interface, IPS all view, a brightness of 1230 Nits with a Capacative Touch Panel.
165.0 x 104.0 x 10.86
154.214 x 85.92
ASI-T-700JA14LN/AE is a 7 inch TFT with a resolution of 1024 x 600, LVDS interface, IPS all view, a brightness of 1400 Nits, ideal for outdoor viewing.
165.0 x 104.0 x 9.31
ASI-T-700MAKFN/A is an industrial grade, high reliability, 7 inch TFT with a resolution of 800 x 480, 24-bit RGB interface, wide temperature range, IPS all view and with a high brightness of 1000 Nits; viewable in direct sunlight.
165.0 x 104.0 x 8.4
152.40 x 91.44
The ASI-T-800SAA10LN/A is a 8.0 inch TFT 4-lane LVDS interface, full viewing angle, 1280 x 720 resolution and 1000 nits brightness.
1280 X 720
192.80 x 116.90 x 9.85
177.024 x 99.576
ASI-T-900SAA10LN/A is a 9.0 inch IPS all-view TFT with a resolution of 1280 x 720, LVDS interface and with a high brightness of 1000 Nits and wide operating and storage temperatures.
ASI-T-9204619A10MPN/D is a 9.2 inch wide Bar-Type, all-view TFT, with a resolution of 462 x 1920, MIPI interface and a high brightness of 1000 Nits; viewable in direct sunlight.
ASI-T-10251248AKLN/D is a 10.25 inch wide TFT, with a resolution of 1280 x 480, LVDS interface, IPS all view, with wide temperature operation and storage and a high brightness of 1,000 Nits.
1280 x 480
258.60 x 107.00 x 6.31
243.84 x 91.44
