TFT Specifications

Displays

ASI-T-1302A3SRN/D is a 1.3 inch TFT with a resolution of 240 x 240, IPS, SPI interface, and a brightness of 320 Nits.

PRODUCTS SPECS
PDF
Interface SPI
Size 1.3
Touch Panel None
Brightness/Nits Range 100-399
Resolution 240 x 240
Module Size 26.0 x 29.15 x 1.4
Active Area 23.40 x 23.40
Polarizer Transmissive
Brightness/Nits 320
Viewing Direction IPS/All-view

ASI-T-1542A3MU6/AM is a 1.54 inch TFT with a resolution of 240 x 240, IPS, MCU interface, a brightness of 350 Nits with a Capacitive Touch Panel.

PRODUCTS SPECS
PDF

Size 1.54
Resolution 240 x 240
Interface MCU
Touch Panel Capacitive Touch Panel
Brightness/Nits Range 100-399
Module Size 31.52 x 33.72 x 1.85
Active Area 27.72 x 27.72
Polarizer Transmissive
Brightness/Nits 350
Viewing Direction IPS/All-view

ASI-T-1542A5BPN/A is a 1.54 inch high brightness TFT with a resolution of 240 x 240, CPU, IPS interface and with a brightness of  500 Nits; viewable in direct sunlight

PRODUCTS SPECS
PDF
Interface CPU
Size 1.54
Touch Panel None
Brightness/Nits Range 400-699
Resolution 240 x 240
Module Size 31.52 x 33.72 x 1.8
Active Area 27.72 x 27.72
Polarizer Transmissive
Brightness/Nits 500
Viewing Direction IPS/All-view

ASI-T-17711A1FN/D is a 1.77 inch transflective TFT with a resolution of  160 x 128, 80-System 8/16-bit interface and with a brightness of  110 Nits; viewable in direct sunlight

PRODUCTS SPECS
PDF

Interface Other
Size 1.77
Touch Panel None
Brightness/Nits Range 100-399
Resolution 160 x 128
Module Size 40.77 x 36.20 x 2.20
Active Area 35.28 x 27.71
Polarizer Transflective
Brightness/Nits 110
Viewing Direction

ASI-T-177BA28N/D is a 1.77 inch TFT with a resolution of 128 x 160, CPU interface, with a brightness of 200 Nits.

PRODUCTS SPECS
PDF
Interface CPU
Size 1.77
Touch Panel None
Brightness/Nits Range 100-399
Resolution 128 x 160
Module Size 34.70 x 46.70 x 2.6
Active Area 28.03 x 35.04
Polarizer Transmissive
Brightness/Nits 200
Viewing Direction 6:00

ASI-T-177BE2IN/D is a 1.77 inch TFT with a resolution of 128 x 160, 8 bit CPU interface, with a brightness of 200 Nits.

PRODUCTS SPECS
PDF

Interface CPU
Size 1.77
Touch Panel None
Brightness/Nits Range 100-399
Resolution 128 x 160
Module Size 34.70 x 46.70 x 2.6
Active Area 35.04 x 28.03
Polarizer Transmissive
Brightness/Nits 200
Viewing Direction 6:00

ASI-T-20043A5PMN/AY is a 2.0 inch TFT with a resolution of 480 x 360, 3W SPI+16 bit RGB or MIPI interface, IPS all view, with a high brightness of 500 Nits.

PRODUCTS SPECS
PDF

Interface MIPI, RGB, SPI
Size 2
Touch Panel None
Brightness/Nits Range 400-699
Resolution 480 x 360
Module Size 46.16 x 40.97 x 2.4
Active Area 40.824 x 30.618
Polarizer Transmissive
Brightness/Nits 500
Viewing Direction IPS/All-view

ASI-T-200CA2IN/D is a 2.0 inch TFT with a resolution of 176 x 220, CPU interface, with a brightness of 220 Nits.

PRODUCTS SPECS
PDF
Interface CPU
Size 2
Touch Panel None
Brightness/Nits Range 100-399
Resolution 176 x 220
Module Size 38.03 x 51.65 x 2.5
Active Area 31.68 x 39.60
Polarizer Transmissive
Brightness/Nits 220
Viewing Direction 6:00

ASI-T-200DA2SMN/AY is a 2.0 inch IPS TFT with a resolution of 240 x 320, 4W SPI or MCU 8Bit  interface, contrast of 800 and a brightness of 220 Nits.

PRODUCTS SPECS
PDF

Interface MCU, SPI
Size 2
Touch Panel None
Brightness/Nits Range 100-399
Resolution 240 x 320
Module Size 36.05 x 51.8 x 2.0
Active Area 30.6 x 40.8
Polarizer Transmissive
Brightness/Nits 220
Viewing Direction IPS/All-view

ASI-T-200EA6SRN/D is a 2.0 inch IPS TFT with a resolution of  320 x 240, SPI or RGB  interface, contrast of 1,500 and a brightness of 620 Nits.

PRODUCTS SPECS
PDF

Interface RGB, SPI
Size 2
Touch Panel None
Brightness/Nits Range 400-699
Resolution 320 X 240
Module Size 46.10 x 40.96 x 2.54
Active Area 40.8 x 30.6
Polarizer Transmissive
Brightness/Nits 620
Viewing Direction IPS/All-view

ASI-T-2201DA0EN/W is a 2.2 inch TFT with a resolution of 240 x 320, RGB interface and with a brightness of  90 Nits; Transflective - viewable in direct sunlight.

PRODUCTS SPECS
PDF
Interface RGB
Size 2.2
Touch Panel None
Brightness/Nits Range 0-99
Resolution 240 x 320
Module Size 40.6 x 56.6 x 2.7
Active Area 33.84 x 45.12
Polarizer Transflective
Brightness/Nits 90
Viewing Direction 12:00

ASI-T-220DA3RN/D is a 2.2 inch TFT with a resolution of 240 x 320, RGB/MCU interface, with a brightness of 330 Nits.

PRODUCTS SPECS
PDF

Interface MCU, RGB
Size 2.2
Touch Panel None
Brightness/Nits Range 100-399
Resolution 240 x 320
Module Size 38.50 x 56.16 x 2.35
Active Area 33.84 x 5.12
Polarizer Transmissive
Brightness/Nits 330
Viewing Direction 6:00

ASI-T-240DA216N/D is a 2.4 inch TFT with a resolution of 240 x 320, MCU interface, with a brightness of 250 Nits.

PRODUCTS SPECS
PDF

Interface MCU
Size 2.4
Touch Panel None
Brightness/Nits Range 100-399
Resolution 240 x 320
Module Size 42.72 x 60.26 x 2.2
Active Area 36.72 x 48.96
Polarizer Transmissive
Brightness/Nits 250
Viewing Direction 6:00

ASI-T-240DA2AN/AY is a 2.4 inch TFT with a resolution of 240 x 320, MCU and RGB interface, IPS-all view, and with a brightness of  220 Nits

PRODUCTS SPECS
PDF

Interface MCU, RGB
Size 2.4
Touch Panel None
Brightness/Nits Range 100-399
Resolution 240 x 320
Module Size 42.72 x 59.46 x 2.35
Active Area 36.72 x 48.96
Polarizer Transmissive
Brightness/Nits 220
Viewing Direction IPS/All-view

ASI-T-240DA2MUN/D is a 2.4 inch TFT with a resolution of  240 x 320, IPS, RGB/MCU interface and a brightness of 220 Nits.

PRODUCTS SPECS
PDF
Interface MCU, RGB
Size 2.4
Touch Panel None
Brightness/Nits Range 100-399
Resolution 240 x 320
Module Size 42.72 x 60.26 x 2.5
Active Area 36.72 x 48.96
Polarizer Transmissive
Brightness/Nits 220
Viewing Direction IPS/All-view

ASI-T-240DA3AN/AY is a 2.4 inch TFT with a resolution of 240 x 320, MCU, AV interface and with a brightness of  300 Nits

PRODUCTS SPECS
PDF

Interface MCU
Size 2.4
Touch Panel None
Brightness/Nits Range 100-399
Resolution 240 x 320
Module Size 42.72 x 60.26 x 2.35
Active Area 36.72 x 48.96
Polarizer Transmissive
Brightness/Nits 300
Viewing Direction IPS/All-view

ASI-T-240DA3MUN/D is a 2.4 inch TFT with a resolution of  240 x 320, RGB stripes interface and a brightness of 320 Nits.

PRODUCTS SPECS
PDF

Interface RGB
Size 2.4
Touch Panel None
Brightness/Nits Range 100-399
Resolution 240 x 320
Module Size 42.70 x 60.20 x 2.4
Active Area 36.72 x 48.96
Polarizer Transmissive
Brightness/Nits 320
Viewing Direction 6:00
ASI-T-240DA8BN/D is a 2.4 inch high brightness TFT with a resolution of 240 X 320, CPU 16-bit interface and with a brightness of 800 Nits; viewable in direct sunlight.
PRODUCTS SPECS
PDF

Interface CPU
Size 2.4
Touch Panel None
Brightness/Nits Range 700-999
Resolution 240 x 320
Module Size 42.72 x 59.4 x 2.15
Active Area 36.72 x 48.96
Polarizer Transmissive
Brightness/Nits 800
Viewing Direction 6:00

ASI-T-240DA10SMN/AQ is a 2.4 inch high brightness TFT with a resolution of 240 x 320, SPI & MCU interface, IPS all-angle view and with a brightness of 1000 Nits; viewable in direct sunlight.  It also features an extra wide operating temperatures of -30 to +80C; perfect for extreme environmental applications.

PRODUCTS SPECS
PDF
Interface MCU, SPI
Size 2.4
Touch Panel None
Brightness/Nits Range 1000 & up
Resolution 240 x 320
Module Size 42.72 x 60.26 x 2.20
Active Area 36.72 x 48.96
Polarizer Transmissive
Brightness/Nits 1000
Viewing Direction IPS/All-view

ASI-T-240DAKBN/D is a 2.4 inch high brightness TFT with a resolution of 240 x 320, MCU interface and with a brightness of 1000 Nits; viewable in direct sunlight.

PRODUCTS SPECS
PDF
Interface MCU
Size 2.4
Touch Panel None
Brightness/Nits Range 1000 & up
Resolution 240 x 320
Module Size 42.72 x 60.35 x 2.90
Active Area 36.72 x 48.96
Polarizer Transmissive
Brightness/Nits 1000
Viewing Direction 6:00

ASI-T-240DB2BN/D is a 2.4 inch TFT with a resolution of 240 x 320, 16-bit CPU interface and with a brightness of  200 Nits.

PRODUCTS SPECS
PDF
Interface CPU
Size 2.4
Touch Panel None
Brightness/Nits Range 100-399
Resolution 240 x 320
Module Size 42.72 x 60.26 x 2.20
Active Area 36.72 X 48.96
Polarizer Transmissive
Brightness/Nits 200
Viewing Direction 6:00

ASI-T-280DA216T/AW is a 2.8 inch TFT with a resolution of 240 x 320, MCU interface, a brightness of 235 Nits with a Resistive Touch Panel.

PRODUCTS SPECS
PDF

Interface MCU
Size 2.8
Touch Panel Resistive Touch Panel
Brightness/Nits Range 100-399
Resolution 240 x 320
Module Size 50.0 x 69.2 x 2.30
Active Area 43.2 x 57.6
Polarizer Transmissive
Brightness/Nits 235
Viewing Direction 6:00

ASI-T-280DA2MU6/AF is a 2.8 inch TFT with a resolution of 240 x 320, MCU interface, a brightness of 200 Nits with a Capacitive Touch Panel.

PRODUCTS SPECS
PDF

Interface MCU
Size 2.8
Touch Panel Capacitive Touch Panel
Brightness/Nits Range 100-399
Resolution 240 x 320
Module Size 50.0 x 69.2 x 4.0
Active Area 43.2 x 57.6
Polarizer Transmissive
Brightness/Nits 200
Viewing Direction 6:00

ASI-T-280DA4MPN/AY is a 2.8 inch TFT with a resolution of 240 x 320, MIPI interface, IPS all view display with a brightness of 420 Nits.

PRODUCTS SPECS
PDF

Interface MIPI
Size 2.8
Touch Panel None
Brightness/Nits Range 400-699
Resolution 240 x 320
Module Size 50.0 x 69.2 x 2.25
Active Area 43.2 x 57.6
Polarizer Transmissive
Brightness/Nits 420
Viewing Direction IPS/All-view
