ASI-T-10101B2MP6/AT is a 10.1 inch TFT with a resolution of 800 x 1280, 4-lane MIPI interface, a brightness of 230 Nits with a Capacitive Touch Panel.

TFT Specifications
Size 10.1

800 x 1280

Module Size

151.65 x 242.75 x 5.1

Active Area

135.36 x 216.576

Interface MIPI
Touch Panel Capacitive Touch Panel
Brightness/Nits Range 100-399
Brightness/Nits 230

Polarizer Transmissive
Viewing Direction IPS/All-view
